Pro Power Controller TD100A

Technical Specification

●Input voltage: AC220V/50HZ ; Rated power: 3200W, total capacity 10A

●Output power: the maximum output current of each socket is 10A

●Multimedia power socket ; AC voltage indicator

●Weight: 3.42KG ; Specifications (length * width * height) mm: 1U case 425*265*48

●Input mode: 3*2.5 square AC power cord, without plug, connected with air switch ; Output mode: 8 power outputs, standard universal three-pin socket

●Function: when opening, start one by one from the front stage to the back stage, and close one by one from the back stage to the front stage when closing, the action time between each channel is 1.5 seconds

●Switch/indication: rocker switch, panel power indicator light, indication after each channel is energized

●Factory configuration: finished product, manual, certificate, warranty card

The TD100A sequencer has 8 high-power power outputs, one-button control of power sequence action, optional power-on and manual functions, suitable for audio engineering, TV broadcasting systems, computer network systems and power facilities that require orderly power distribution systems occasion The TD100A power sequencer can start the equipment one by one from the front stage to the back stage. When the power supply is turned off, the power equipment will be turned off from the back stage to the front stage, so that it can effectively manage and control all kinds of electrical equipment. Man-made mistakes. Ensure the stability of the entire audio power system during operation.
